Horizontal Direction Drilling Grade Bentonite Lumps

Get a Price/Quote

MOQ : 28 MT Metric Tons

Horizontal Direction Drilling Grade Bentonite Lumps Specification

Product Type
Bentonite Products

Density
1.3 Gram per cubic centimeter(g/cm3)

Strength
High swelling and bonding strength

Moisture
8% Max

Dimension (L*W*H)
Lumps form, size varies

Appearance
Natural lumps

Application
Horizontal Directional Drilling, Piling, Foundation

Color
Brownish to cream

pH Value
9.0 - 11.0

Solubility
Insoluble in water, forms gel

Yield
200 - 220 barrels per ton

Sand Content
Less than 2%

Swelling Index
32-34 ml/2g min

Colloidal Content
80% Minimum

Gel Formation Time
Quick

Horizontal Direction Drilling Grade Bentonite Lumps Trade Information

Minimum Order Quantity
28 MT Metric Tons

FOB Port
MUNDRA

Payment Terms
Delivery Point (DP), Letter of Credit (L/C), Telegraphic Transfer (T/T), Western Union, Days after Acceptance (DA)

Supply Ability
26000 Metric Tons Per Month

Delivery Time
5 Days

Sample Available
Yes

Sample Policy
Free samples are available

Packaging Details
Customized and durable packaging, 25kgs & 40 kgs paper bags with liner, PP bags with liner 25 kgs & 50 kgs With and Without pallets, Jumbo bags in 1000 kgs, 1250 kgs, 1350 kgs, 1375kgs & 1400 kgs.

Main Export Market(s)
Western Europe, Australia, North America, Eastern Europe, Middle East, South America, Asia, Central America, Africa

About Horizontal Direction Drilling Grade Bentonite Lumps

Indias one of the largest bentonitemines owner, processor and exporter. We are exporting super premium qualityBentonite at competitive prices with prompt shipments. We provide all types ofpacking with customized printing options. The Horizontal Directional Drilling of pipelines puts a non-hazardousdrilling mud comprising of water and Bentonite to extensive use. Bentonite iswidely used as it introduces cutting carrying capacity to flush the bore hole.Our provided all bentonite is mined in the Kachchh Gujarat, India.

WHY CMS INDUSTRIES?

CMS grade Horizontal Directional Drillingbentonite is eco-friendly, with having high quality drilling fluids whichmitigates fluid loss, reduces torque and regulates down hole conditions of HDD.And it is non-petroleum lubricant perfected for horizontal directional drillingand the related applications.

Superior Swelling and Bonding Strength

Our bentonite lumps possess high swelling capacity and exceptional bonding strength, crucial for stabilizing drilling fluids and formations during HDD and piling. The rapid gel formation and consistent dimension help maintain efficiency and safety in construction sites, ensuring reliable results across varied project scales.

Optimal Colloidal Content and Purity

With a colloidal content of at least 80% and sand content under 2%, the quality of these bentonite lumps surpasses standard requirements for the drilling industry. The low moisture and natural appearance reflect minimal processing, maintaining the integrity required for challenging subsurface conditions.

Versatility Across Applications

Bentonite lumps are suitable for horizontal directional drilling, piling, and foundation work. Their quick gel formation and high yield make them indispensable for ensuring smooth drilling processes and enduring structural support in geotechnical and civil engineering.

FAQ's of Horizontal Direction Drilling Grade Bentonite Lumps:

Q: How are Horizontal Direction Drilling Grade Bentonite Lumps used in HDD applications?

A: These bentonite lumps are mixed with water onsite, forming a gel that acts as a drilling fluid. This fluid stabilizes boreholes, cools drill bits, manages debris, and prevents collapse during horizontal directional drilling operations.

Q: What benefits do the swelling index and gel formation time offer for drilling?

A: A swelling index of 32-34 ml/2g and quick gel formation time ensure rapid development of a viscous barrier, leading to better stability, enhanced cutting transport, and improved borehole integrity throughout the drilling process.

Q: When should this grade of bentonite be selected for foundation or piling projects?

A: This grade is ideal for projects requiring rapid gel formation, high colloidal content, and minimal sand presence. It is especially suited when strong stabilization and high yield are needed for complex foundation or piling works.

Q: Where are these bentonite lumps sourced and supplied from?

A: Our bentonite lumps are manufactured, exported, and supplied by leading companies based in India, known for their consistent quality and adherence to global industrial standards.

Q: What is the process for preparing bentonite lumps for drilling usage?

A: The lumps are collected in their natural state, size-graded, and quality-checked, then mixed with water to form the required slurry at the drilling site, optimizing fluid characteristics for specific project needs.

Q: How does the product's insolubility in water affect its performance?

A: Since the bentonite is insoluble in water and forms a gel, it provides a stable and continuous matrix within boreholes. This enhances fluid circulation, reduces drag, and protects structural integrity during drilling.
